Model |
WSD-6FPS-1 |
|
|
Cylinder diameter |
3.75inch-4inch |
|
|
Can be made 4.5,5.6,3.5inch caliber syring,various needlers. |
||
|
Needle Number |
132-144N |
|
|
Max speed |
Max speed 320rpm/min |
|
|
Running speed |
220 rpm/min |
|
|
Function |
1 Can choose one color or double color elastic |
|
|
2. According to customer needs. Special kinds of machines can be ordered |
||
|
3. One feeder or two feeder into yarn to knit singe/double welt design |
||
| 4. 5 color in one line, total 10 color in one sock | ||
|
5. Can knit all kinds of plain invisible socks |
||
|
Power Requirement |
Driver motor |
0.85 KW |
|
Fun motor |
0.75 KW |
|
|
Control box |
0.80 KW |
|
|
Voltage |
220V/380V/415V |
|
|
Floor space |
150×120×240cm |
|
|
Net/Gross weight |
300/350 KG |
|
|
Packing size(L×W×H) |
110×75×165cm |
|
Main features:
1. Drumless & full computerized control system
2. Two main feeder plus five pattern feeder for possibility of 16 colors
3. Double pickers to decrease the extent of to-and-fro running for making toe and heel, increasing the knitting speed and enable to make 3D sock.
4.Automatic lubrication device; Automatic oil pump system.
5.Error self-check and machine stop automatically, error information showing on LCD.
6.Simple and convenient pattern designing system.
7. Possibility to modify the density, speed, cycles for each step.
8.Modification of needle number and gauge could could be operated after changing cylinder.
9.Using USB interface for easier data reading and storage.
