Model |
WSD-6FPT-I |
|
|
Cylinder diameter |
3.5inch/3.75inch/4inch/4.5inch |
|
|
Needle Number |
Terry : 72-176N |
|
|
Max speed |
320rpm/min |
|
|
Running speed |
220 rpm/min |
|
|
Function |
1. Can choose one color or double elastic |
|
|
2. According to customer's needs. special kinds of machines can be ordered |
||
|
3. One feeder or two feeder into yarn to knit single/double welt design |
||
|
4. 6 color in 1 line, total 13 color in one sock |
||
|
5. The maximum horizontal stroke pulls is 39cm |
||
|
6.Can select the socks of varicose veins connected rubber fully |
||
|
7. Can knit all kinds of plain invisible socks |
||
|
Power Requirement |
Driver motor |
0.85 KW |
|
Fun motor |
0.75 KW |
|
|
Control box |
0.80 KW |
|
|
Voltage |
220V/380V/415V |
|
|
Floor space |
150×120×240cm |
|
|
Net/Gross weight |
300/350 KG |
|
|
Packing size(L×W×H) |
110×75×165cm |
|
 |
 |
 |
 |
 |
 |
 |
 |
 |
Technical Character:
1. it adopts computer-controlled device , which has close structure, complete function and feasible operation. the in/out operation of every brake of this device is controlled by date and the style of socks is changed by the input of patters and chain procedure .
2.. the yarn-sending speed of the elastic is controlled by step-advancing motor and can knit varies of elastic sock tubes .
3. it adopts clear and big display screen with selection of languages includes Chinese ,English and Russian so the data of computer is very clear .
4. the pattern can be saved after accidental power off or other problems , and the last work procedure can be automatically continued after restart .
5. accident checking perfect and protection system of thread-break and needle-break is very sensitive .
